Wire connector СК-413 (2.5 мм2) (50pcs/bag) ЮПИТЕР
Vendor code:
JP7201-05
| Barcode: | 5290203900770 ( ) |
| Dimensions LxWxH, cm: | 12.5 x 8 x 4 |
| Weight with packaging, kg: | 0.16 |
Prices
Recommended retail price USD excluding VAT
7,27
$
Remainings
In stock Ningbo
pcs.
Characteristics:
- Specifications
- Purpose
- used for connecting copper single-core or multi-core conductors, for mounting conductors in a junction box, connecting lamps and other equipment
- Cross-section of the conductor to be connected
- 0.1 - 2.5 mm2 (for solid conductors), 0.08 - 4 mm2 (for stranded conductors)
- Number of clamps
- 3 pcs
- Clamping type
- push lever
- Rated current
- 24 A (2,5 mm2), 32 A (4 mm2)
- Rated voltage
- 380 V
- Operating temperature
- -25 to +80 °С
Advantages:
■
■ Advantages:
■ - test hole for the possibility of measuring electrical parameters without disassembling and breaking the insulation of the connection;
