Cable F/UTP Cat5E Indoor 4х2х24AWG (0.51мм) 305м, Cu, PVC ЮПИТЕР
Code:
1023806
Vendor code:
JP3010
| Barcode: | 5290203100217 ( ) |
| Dimensions LxWxH, cm: | 44 x 36.5 x 37 |
| Weight with packaging, kg: | 9.5 |
Prices
Last price
137,23
$
Remainings
In stock Ningbo
pcs.
| Barcode: | 5290203100217 ( ) |
| Dimensions LxWxH, cm: | 44 x 36.5 x 37 |
| Weight with packaging, kg: | 9.5 |
Equipment:
Specifications: Application: indoor; local area networks, computer networks, data networks, digital television, video surveillance systems, user networking, telephony, security and access control systems, PoE, home networks; Cable kind: F/UTP (FTP); Category: 5E; Number of pairs: 4; Cable type: shielded; Outer sheath material: PVC (polyvinyl chloride); Conductor Material: copper; Conductor thickness: 0,51mm (AWG 24); Voltage: not more than 50V; Cable length: 305m; Cable Colour: Grey; Service life: 20 years; --- Compatible Products: JP7306 Connector (jack) computer RJ-45 8P8C CAT 5e (100pcs) JUPITER; JPZ1-7306-10 RJ-45 8P8C CAT 5e computer jack (10 pcs.) JPITER; JPZ1-7308-2 Connector (jack) computer RJ-45 8P8C with cap (2 pcs. each) JUPITER; --- High quality copper cable Jupiter is manufactured in compliance with all standards. The four-pair cable has the following construction: the conductor is a solid copper core with a diameter of 24AWG (0,51mm). Two conductors make one twisted pair, in general, the cable consists of four pairs, twisted with different, specially selected pitch. For better signal transmission, the cable has a common screen under the outer sheath in the form of aluminium foil, which provides additional protection from external electromagnetic interference. The cable is marked with the cable category, number of pairs, type and diameter of the copper conductor, as well as length markings every metre. LAN-cables are delivered in cardboard boxes of 305m. For reliable and high-quality crimping it is recommended to use Jupiter jacks and crimpers.
